104.1. Create partitions and filesystems

Weight: 2

Description: Candidates should be able to configure disk partitions and then create filesystems on media such as hard disks. This includes the handling of swap partitions.

Objective

  • Use various mkfs commands to set up partitions and create various filesystems such as:
  • ext2/ext3/ext4
  • xfs
  • reiserfs v3
  • vfat
  • fdisk
  • mkfs
  • mkswap

Blocked devices

Is a technical term for any storage device which can be formatted to fixed sized blocks and blocks should be able to be accessed individually. That is Hard disks, USB Memories, CDs, ..

In long ls format, the first b indicates Block Device:

$ ls -l /dev/loop1  /dev/sd[a-z]
brw-rw---- 1 root disk 7, 1 Jan  8 10:46 /dev/loop1
brw-rw---- 1 root disk 8, 0 Jan  8 10:46 /dev/sda

Some block devices mostly used as one single filesystem (like CDs & Floppies) and some are divided into Partitions (Hard disks).

fdisk

fdisk is the main command for viewing / changing and creating partitions. -l switch is for show:

[email protected]:~# fdisk -l /dev/sda

Disk /dev/sda: 298.1 GiB, 320072933376 bytes, 625142448 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x000beca1

Device     Boot     Start       End   Sectors   Size Id Type
/dev/sda1  *         2048  43094015  43091968  20.6G 83 Linux
/dev/sda2        43094016  92078390  48984375  23.4G 83 Linux
/dev/sda3        92080126 625141759 533061634 254.2G  5 Extended
/dev/sda5        92080128 107702271  15622144   7.5G 82 Linux swap / Solaris
/dev/sda6       107704320 625141759 517437440 246.8G 83 Linux
  • The Boot flag shows which partition starts the boot on DOS PCs and has no importance on LILO & GRUB
  • Start and End shows the where this partition is located on the disk
  • Size is size!
  • ID indicated the partition format (82 is swap, 83 is linux data, ..)

It is also possible to run fdisk in interactive mode. m will show you the help:

[email protected]:~# fdisk /dev/sda

Welcome to fdisk (util-linux 2.25.1).
Changes will remain in memory only, until you decide to write them.
Be careful before using the write command.


Command (m for help): m

Help:

  DOS (MBR)
   a   toggle a bootable flag
   b   edit nested BSD disklabel
   c   toggle the dos compatibility flag

  Generic
   d   delete a partition
   l   list known partition types
   n   add a new partition
   p   print the partition table
   t   change a partition type
   v   verify the partition table

  Misc
   m   print this menu
   u   change display/entry units
   x   extra functionality (experts only)

  Save & Exit
   w   write table to disk and exit
   q   quit without saving changes

  Create a new label
   g   create a new empty GPT partition table
   G   create a new empty SGI (IRIX) partition table
   o   create a new empty DOS partition table
   s   create a new empty Sun partition table

p displays the current partitions:

Command (m for help): p
Disk /dev/sda: 298.1 GiB, 320072933376 bytes, 625142448 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x000beca1

Device     Boot     Start       End   Sectors   Size Id Type
/dev/sda1  *         2048  43094015  43091968  20.6G 83 Linux
/dev/sda2        43094016  92078390  48984375  23.4G 83 Linux
/dev/sda3        92080126 625141759 533061634 254.2G  5 Extended
/dev/sda5        92080128 107702271  15622144   7.5G 82 Linux swap / Solaris
/dev/sda6       107704320 625141759 517437440 246.8G 83 Linux

You may remember the disk layouts from other chapters. fdisk can create them. Lets first delete my first partition:

Command (m for help): p
Disk /dev/sda: 298.1 GiB, 320072933376 bytes, 625142448 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x000beca1

Device     Boot     Start       End   Sectors   Size Id Type
/dev/sda1  *         2048  43094015  43091968  20.6G 83 Linux
/dev/sda2        43094016  92078390  48984375  23.4G 83 Linux
/dev/sda3        92080126 625141759 533061634 254.2G  5 Extended
/dev/sda5        92080128 107702271  15622144   7.5G 82 Linux swap / Solaris
/dev/sda6       107704320 625141759 517437440 246.8G 83 Linux


Command (m for help): d
Partition number (1-3,5,6, default 6): 1

Partition 1 has been deleted.

I'm brave! Now lets create a smaller one there:

Command (m for help): n
Partition type
   p   primary (1 primary, 1 extended, 2 free)
   l   logical (numbered from 5)
Select (default p): p
Partition number (1,4, default 1): 1
First sector (2048-625142447, default 2048):
Last sector, +sectors or +size{K,M,G,T,P} (2048-43094015, default 43094015): +15G

Created a new partition 1 of type 'Linux' and of size 15 GiB.

Command (m for help): p
Disk /dev/sda: 298.1 GiB, 320072933376 bytes, 625142448 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x000beca1

Device     Boot     Start       End   Sectors   Size Id Type
/dev/sda1            2048  31459327  31457280    15G 83 Linux
/dev/sda2        43094016  92078390  48984375  23.4G 83 Linux
/dev/sda3        92080126 625141759 533061634 254.2G  5 Extended
/dev/sda5        92080128 107702271  15622144   7.5G 82 Linux swap / Solaris
/dev/sda6       107704320 625141759 517437440 246.8G 83 Linux

This new partitioned is not formatted but still marked 83 for later use. If I needed to use this partition as swap I had to set its ID to 82:

Command (m for help): p
Disk /dev/sda: 298.1 GiB, 320072933376 bytes, 625142448 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x000beca1

Device     Boot     Start       End   Sectors   Size Id Type
/dev/sda1            2048  31459327  31457280    15G 83 Linux
/dev/sda2        43094016  92078390  48984375  23.4G 83 Linux
/dev/sda3        92080126 625141759 533061634 254.2G  5 Extended
/dev/sda5        92080128 107702271  15622144   7.5G 82 Linux swap / Solaris
/dev/sda6       107704320 625141759 517437440 246.8G 83 Linux


Command (m for help): t
Partition number (1-3,5,6, default 6): 1
Hex code (type L to list all codes): L

 0  Empty           24  NEC DOS         81  Minix / old Lin bf  Solaris
 1  FAT12           27  Hidden NTFS Win 82  Linux swap / So c1  DRDOS/sec (FAT-
 2  XENIX root      39  Plan 9          83  Linux           c4  DRDOS/sec (FAT-
 3  XENIX usr       3c  PartitionMagic  84  OS/2 hidden C:  c6  DRDOS/sec (FAT-
 4  FAT16 <32M      40  Venix 80286     85  Linux extended  c7  Syrinx
 5  Extended        41  PPC PReP Boot   86  NTFS volume set da  Non-FS data
 6  FAT16           42  SFS             87  NTFS volume set db  CP/M / CTOS / .
 7  HPFS/NTFS/exFAT 4d  QNX4.x          88  Linux plaintext de  Dell Utility
 8  AIX             4e  QNX4.x 2nd part 8e  Linux LVM       df  BootIt
 9  AIX bootable    4f  QNX4.x 3rd part 93  Amoeba          e1  DOS access
 a  OS/2 Boot Manag 50  OnTrack DM      94  Amoeba BBT      e3  DOS R/O
 b  W95 FAT32       51  OnTrack DM6 Aux 9f  BSD/OS          e4  SpeedStor
 c  W95 FAT32 (LBA) 52  CP/M            a0  IBM Thinkpad hi eb  BeOS fs
 e  W95 FAT16 (LBA) 53  OnTrack DM6 Aux a5  FreeBSD         ee  GPT
 f  W95 Ext'd (LBA) 54  OnTrackDM6      a6  OpenBSD         ef  EFI (FAT-12/16/
10  OPUS            55  EZ-Drive        a7  NeXTSTEP        f0  Linux/PA-RISC b
11  Hidden FAT12    56  Golden Bow      a8  Darwin UFS      f1  SpeedStor
12  Compaq diagnost 5c  Priam Edisk     a9  NetBSD          f4  SpeedStor
14  Hidden FAT16 <3 61  SpeedStor       ab  Darwin boot     f2  DOS secondary
16  Hidden FAT16    63  GNU HURD or Sys af  HFS / HFS+      fb  VMware VMFS
17  Hidden HPFS/NTF 64  Novell Netware  b7  BSDI fs         fc  VMware VMKCORE
18  AST SmartSleep  65  Novell Netware  b8  BSDI swap       fd  Linux raid auto
1b  Hidden W95 FAT3 70  DiskSecure Mult bb  Boot Wizard hid fe  LANstep
1c  Hidden W95 FAT3 75  PC/IX           be  Solaris boot    ff  BBT
1e  Hidden W95 FAT1 80  Old Minix
Hex code (type L to list all codes): 82

Changed type of partition 'Linux' to 'Linux swap / Solaris'.

Command (m for help): p
Disk /dev/sda: 298.1 GiB, 320072933376 bytes, 625142448 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x000beca1

Device     Boot     Start       End   Sectors   Size Id Type
/dev/sda1            2048  31459327  31457280    15G 82 Linux swap / Solaris
/dev/sda2        43094016  92078390  48984375  23.4G 83 Linux
/dev/sda3        92080126 625141759 533061634 254.2G  5 Extended
/dev/sda5        92080128 107702271  15622144   7.5G 82 Linux swap / Solaris
/dev/sda6       107704320 625141759 517437440 246.8G 83 Linux

b is code for FAT32 (windows 95).

But all we done was in memory! We need to write it to the partition table. 'v' will verify the setup:

Command (m for help): v
Remaining 11639159 unallocated 512-byte sectors.

It tells me that I have unallocated space! I'm waisting my hard but I'm fine with it. So lets save it with w command (for write):

Command (m for help): w

The partition table has been altered.
Calling ioctl() to re-read partition table.
Re-reading the partition table failed.: Device or resource busy

The kernel still uses the old table. The new table will be used at the next reboot or after you run partprobe(8) or kpartx(8).

Formatting the partition

Linux can handle more than 100 kind of partitions but most commons are:

FormatDescription
ext2 second extended filesystem was developed to address shortcomings in the Minix filesystem used in early versions of Linux. It has been used extensively on Linux for many years. There is no journaling in ext2, and it has largely been replaced by ext3 and more recently ext4.
ext3 ext2 + journaling, total storage can be 1EXAByte and each file can be 16TB, ...
ReiserFS ReiserFS is a B-tree-based filesystem, great for large numbers of small files, journaling, no longer in active development & does not support SELinux, replaced with Reiser4.
XFS journaling, caches to RAM, great for uninterruptible power supplies
swap Swap space must be formatted for use as swap space, but it is not generally considered a filesystem.
vfat FAT32, no journaling, good for data exchange with windows, does not understand permissions and symbolic links
ext4 newer than ext3

You can format your partitions with mkfs command (and mkswap for swap). This is a front end to commands like mkfs.ext3 for ext3, mkfs.ext4 for ext4 and mkfs.reiserfs for ReiserFS. full list of installed on your system is here:

[email protected]:~# ls /sbin/mk*
/sbin/mkdosfs  /sbin/mkfs      /sbin/mkfs.cramfs  /sbin/mkfs.ext3  /sbin/mkfs.ext4dev  /sbin/mkfs.minix  /sbin/mkfs.ntfs  /sbin/mkhomedir_helper  /sbin/mkswap
/sbin/mke2fs   /sbin/mkfs.bfs  /sbin/mkfs.ext2    /sbin/mkfs.ext4  /sbin/mkfs.fat      /sbin/mkfs.msdos  /sbin/mkfs.vfat  /sbin/mkntfs

The main switch is -type (or -t) to specify the format:

[email protected]:~# mkfs -t ext3 /dev/sda1
mke2fs 1.42.10 (18-May-2014)
/dev/sda1 contains a ext4 file system
    last mounted on /mnt on Mon Dec 22 12:04:22 2014
Proceed anyway? (y,n) y
Creating filesystem with 5386496 4k blocks and 1349040 inodes
Filesystem UUID: 0b5aad86-b507-41b9-a0ff-cf899cb92785
Superblock backups stored on blocks:
    32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,
    4096000

Allocating group tables: done
Writing inode tables: done
Creating journal (32768 blocks): done
Writing superblocks and filesystem accounting information: done

[email protected]:~#

This will have a same effect: mkfs.ext3 /dev/sda1

If you need to assign a lable to the partition, you have to use the -L lable_name option. Please note that in renect system, people use UUIDs instead of labels. UUID of a disk can be viewed with:

$ blkid /dev/sda1
/dev/sda1: UUID="59d8cbdb-0e78-4605-8aaf-cf02fcb85d2e" SEC_TYPE="ext2" TYPE="ext3"

GPT

Some systems use GUID Partition Table (GPT) instead of older MBR. In this case you have to use the gdisk tool which has more capabilities than fdisk.

[email protected]:~# gdisk /dev/sda
GPT fdisk (gdisk) version 0.8.8

Partition table scan:
  MBR: MBR only
  BSD: not present
  APM: not present
  GPT: not present


***************************************************************
Found invalid GPT and valid MBR; converting MBR to GPT format
in memory. THIS OPERATION IS POTENTIALLY DESTRUCTIVE! Exit by
typing 'q' if you don't want to convert your MBR partitions
to GPT format!
***************************************************************

creating different partitions

PartitionFormat typeSample CommandNotes
/dev/sda3 ext4 mkfs -t ext4 -L data/dev/sda3 Named it dafa. Or use the mkfs.ext4 command
/dev/sdb2 xfs mkfs -t xfs -i size=512 /dev/sdb2 telling it to have larger inodes (normal is 256)
/dev/sda8 ReiserFS mkfs -t reiserfs /dev/sda8 Or you can use mkreiserfs command.
/dev/sdc FAT32 mkfs -t vfat /dev/sdc Or you can use mkfs.vfat command
/dev/sda2 swap mkswap /dev/sda2 will be used as swap space

No Comments Yet...

Leave a reply

Your email address will not be published.

Top
